Elcometer NDT CG20 Corrosion Ultrasonic Thickness Gauge - Discontinued

PLEASE NOTE: THIS PRODUCT HAS BEEN DISCONTINUED – Please contact us if you would like a recommendation of a unit to replace this model.

elcometer-ndt-cg20-corrosion-ultrasonic-thickness-gauge

Product Description

The Elcometer NDT CG20 Corrosion Ultrasonic Thickness Gauge is a fixed velocity gauge making it an affordable handheld precision tool that requires no special training to operate.

The Elcometer NDT CG20 Corrosion Ultrasonic Thickness Gauge has two user programmable velocities and 8 pre-programmed velocities to measure the thickness of aluminium, steel, stainless steel, cast iron, plexiglass, PVC, polystyrene and polyurethane – making the CG20 an ideal model for the person who tests a few different materials regularly.

This small, lightweight, water resistant unit is easy to use and designed for the harshest environments.

Elcometer NDT CG20 Corrosion Ultrasonic Thickness Gauge Advantages

  • Ready to use, straight from the box
  • Ideal for basic thickness measurements
  • Durable gauge and probe construction
  • Large backlight LED display
  • Tough, impact, water, dust & petroleum product resistant
  • Up to 200 hours battery life



Specifications

Elcometer NDT CG20 Corrosion Ultrasonic Thickness Gauge – Specifications



Model & Part Number CG20
Ultrasonic Corrosion Thickness Gauge
Material thickness digits display
Measurement Mode PE
Measurement Rate Manual 4 readings per second
Measuring Range 0.63 – 500mm
Measurement Accuracy ±0.01mm
Measurement Resolution 0.01mm
Velocity Calibration Range 1250 – 10,000m/s
Additional Features 2 user programmable &
8 pre-calibrated velocities for:
aluminium, cast iron, plexiglass, polystyrene,
polyurethane, PVC, stainless steel & steel
Transducer Probe Type dual element
Transducer Frequency Range 1 – 10MHz
V-path / dual path error correction automatic
Probe zero manual (via integrated probe disk)
Display 12.7mm high digits
Units (selectable) mm or inches
LED Backlight on / off / auto
Repeatability / Stability Indicator
Battery Type 2 x AA alkaline
Battery Life (approximate) 200 hours
Low Battery Indicator
Battery Save Mode auto
Operating Temperature -30 to 50ºC
Size (w x h x d) 63.5 x 114.3 x 31.5mm
Weight (including batteries) 284g
Aluminium case design with
gasket sealed end caps,
waterproof membrane keypad
Transducer Connector Type LEMO
RS232 Interface for programming only



Elcometer NDT CG20 Corrosion Ultrasonic Thickness Gauge Packing List:

  • Elcometer NDT CG20Corrosion Ultrasonic Thickness Gauge
  • Couplant
  • Carry case
  • User manual
  • Test certificate
  • 2 x AA batteries
  • Software
  • Transfer Cable
