Elcometer 115 Stainless Steel Wet Film Combs
Specialist pick
Image 1 / 1
About this product

The Elcometer 115 Stainless Steel Wet Film Combs measure the wet film thickness of a freshly applied coating, supplied with either metric or imperial film thickness markings. Reading thickness while the film is still wet lets an applicator confirm the correct amount of coating is going on, before it cures, which is the practical safeguard against an under- or over-applied film that would otherwise mean stripping back and reapplying once the fault is found dry.

Each comb has 10 measurement steps, or teeth, of stepped lengths. The Elcometer 115 Stainless Steel Wet Film Comb is placed into the wet film and removed, and the wet thickness reads as the value between the highest wet tooth and the lowest dry tooth. Four ranges are available to suit different coatings: 20 to 325µm, 50 to 450µm, 50 to 750µm and 125 to 1250µm, with a set of all four offered together. Accuracy is ±5% of the marked value or 3µm, whichever is greater. The combs are stainless steel for durability and operate manually with no power supply.

They can be used in accordance with ISO 2808-1A, ISO 2808-7B, ASTM D 4414-A, AS/NZS 1580.107.3, BS 3900-C5-7B, NF T30-125, US NAVY PPI 63101-000 and US NAVY NSI 009-32. Used by painters, applicators and coatings inspectors across protective and industrial coating work, they are supplied by BAMR, South Africa's authorised Elcometer distributor.

Elcometer

Elcometer 115 Stainless Steel Wet Film Combs

SKU · B11529455M (+4 more)

The Elcometer 115 Stainless Steel Wet Film Combs are made to be long lasting and are supplied with either Metric or Imperial film thickness measurements. Four separate wet film thickness ranges are available up to a maximum of 1250µm and are manufactured to an accuracy of 5% or 2.5µm, whichever is the greater. Each wet film comb has 10 measurement steps (teeth).

  • Manual operation, no power supply required
  • Spirit filled thermometers
Indicative price
POA
Specialist-built quote, by close of business
Or ask a quick question on WhatsApp
Used by inspection teams in
RefiningMarineMiningBridge / civil
Specifications

Specifications

ο = certificate available

Part NumberRangeMeasurement StepsCertificate
B11529455M20 – 325µm20, 35, 50, 75, 100, 125, 175, 225, 275, 325µmο
B11529456M50 – 450µm50, 75, 100, 150, 200, 250, 300, 350, 400, 450µmο
B11529457M50 – 750µm50, 100, 150, 200, 250, 350, 450, 550, 650, 750µmο
B11529458M125 – 1250µm125, 250, 375, 500, 625, 750, 875, 1000, 1125, 1250µmο
B1152959WMSet of 4 Wet Film Combsο
Accuracy±5% of marked value or 3μm whichever is the greater
Certificate
Optional Available
Standards

Standards

ISO
ISO 2808-1A
ISO
ISO 2808-7B
ASTM
ASTM D 4414-A
AS/NZS
AS/NZS 1580.107.3
BS
BS 3900-C5-7B
NF
NF T30-125
US NAVY
US NAVY PPI 63101-000
US NAVY
US NAVY NSI 009-32
Downloads
Videos

Videos

Answers

Frequently asked questions

Which Elcometer 115 model should I choose?

Select by your typical coating thickness range. The 20-325µm model suits thin coatings; 50-450µm handles mid-range work; 50-750µm covers most industrial applications; 125-1250µm measures thick protective systems. All feature 10 measurement steps and ±5% or 3μm accuracy, whichever is greater.

Can I buy all four thickness ranges together?

Yes. The B1152959WM is a complete set of all four Elcometer 115 combs, covering 20µm to 1250µm in a single purchase.

What accuracy do these combs deliver?

Each comb is manufactured to ±5% of the marked value or 3μm, whichever is greater, ensuring consistent measurements across your coating inspection work.

Are metric and imperial options available?

Yes, these combs are supplied with either metric or imperial film thickness measurements, so you can match your existing inspection protocols.

Can I measure very thick coatings with these?

Yes. The B11529458M measures from 125 to 1250µm, making it suitable for thick protective coating systems and heavy-duty industrial applications.

Are calibration certificates available?

Yes, optional calibration certificates are available with the Elcometer 115 combs, allowing you to document traceability for your quality records.
