The Elcometer 200C Contractor Portable Abrasive Blast Machine (part number M200B-G) is a 200 litre, 12bar portable blast pot built for mobile blasters who need continuous high production blasting. Its large capacity cuts the down time spent refilling the hopper, so a contractor can keep blasting for longer between stops, and its use of industry-standard remote control valves, grit valves and 32mm pipework keeps it competitive and easy to maintain.
The Elcometer 200C Contractor Portable Abrasive Blast Machine runs standard bore 32mm pipework throughout for reliable airflow, with a maximum working pressure of 12bar and an operating temperature range of 0 to 60 degrees C. The automatic general valve has a built-in fail-safe that shuts off both the blast stream and media flow at the handle quickly and safely, reducing wastage. A high-flow concave dish with deflector plate speeds filling, a 45/90 degree fast flow cone maximises abrasive flow rate, and a high-performance moisture separator stops water and oil reaching the pot. Large inspection access wide enough for both arms makes servicing straightforward, and optional waterproof sieves and lids keep media dry. The 200 litre pot of the Elcometer 200C Contractor Portable Abrasive Blast Machine has a 610mm diameter, measures 1380mm high by 794mm wide by 1109mm deep, and weighs 205kg, holding around 468kg of garnet grit or 880kg of steel shot.
The Elcometer 200C Contractor Portable Abrasive Blast Machine is used by mobile and contract abrasive blasting crews in surface preparation, structural steel and marine coatings work. Supplied by BAMR, South Africa's authorised Elcometer distributor.
Elcometer 200C Contractor Portable Abrasive Blast Machine - 12bar
The Elcometer 200C Contractor Abrasive Blast Machine is ideal for mobile blasters requiring continuous high production blasting as its large capacity reduces down time refilling the hopper. Utilising industry standard remote control valves, grit valves and 32mm pipework, the Elcometer 200C Abrasive Blast Machine is highly competitive and easy to maintain.
- Heavy Duty Construction The Elcometer Automatic General Valve has a built in fail-safe feature that shuts off both the blast stream and media flow at the handle quickly and safely - reducing wastage.
- Reliable Performance Standard bore 32mm pipework throughout for reliable airflow performance.
- Concave Dishes Our high flow concave dish comes complete with a deflector plate for fast filling & operator safety.
- Exhaust Manifolds Industry standard exhaust manifolds allow air to exhaust through the silencer safely.
- Fast Flow Cone 45/90° cone to maximise abrasive flow rate.
- Moisture Separators High performance moisture separator prevents water and oil from entering the blast pot.
- Large Inspection Access Elcometer's Contractor abrasive blast machines make inspection and servicing easy, thanks to the large doorway access that is wide enough to fit both arms.
- Waterproof Sieves & Lids Optional sieves & lids are designed to fit over the top of the machine to prevent water ingress, keeping the media dry.
Capacity¹
- Volume
- 200 Litres
- Garnet Grit
- 468kg
- Steel Shot
- 880kg
- ¹
- Aluminium & steel shot capacity figures based on typical media bulk density. Note that bulk density varies according to media size and grade.
General
- Model
- Portable
- Valve
- Standard Grit Valve (SGV)
Dimensions
- Pot Diameter
- 610mm
- Height (a)
- 1380mm
- Width (b)
- 794mm
- Depth (c)
- 1109mm
- Weight
- 205kg
- Pipework Diameter
- 32mm
Performance
- Maximum Working Pressure (WP)²
- 12bar
- Operating Temperature Range
- 0 to 60°C
- ²
- Do not operate this abrasive blast machine unless there is an appropriate safety pressure relief valve within the pressurised system as a whole.
Specifications
Capacity¹
- Volume
- 200 Litres
- Garnet Grit
- 468kg
- Steel Shot
- 880kg
- ¹
- Aluminium & steel shot capacity figures based on typical media bulk density. Note that bulk density varies according to media size and grade.
General
- Model
- Portable
- Valve
- Standard Grit Valve (SGV)
Dimensions
- Pot Diameter
- 610mm
- Height (a)
- 1380mm
- Width (b)
- 794mm
- Depth (c)
- 1109mm
- Weight
- 205kg
- Pipework Diameter
- 32mm
Performance
- Maximum Working Pressure (WP)²
- 12bar
- Operating Temperature Range
- 0 to 60°C
- ²
- Do not operate this abrasive blast machine unless there is an appropriate safety pressure relief valve within the pressurised system as a whole.
What's in the kit
What's in the kit
Spare Parts
Spare Parts
- Pop Up Valve
- MT32050
- Pop-Up Shaft; M200B
- MT32051-3
- 25mm Female Equal Elbow
- MT29611
- Moisture Separator Assembly
- MT28617
- Pipe 32mm
- MT32053
- 6mm Bulkhead Connector (x3)
- MT29664
- Twinline Air Hose Assembly (Yellow & Green)
- MT32054-3
- Pop-Up Valve Ring (x5)
- MT28627-5
- Deflector Plate with Fasteners
- MT32052
- 25mm Backnut
- MT32035
- 25mm Female / Female Union Taper Seat
- MT29673
- 1″ to 3 / 4 " Reducing Hex Nipple (25 x 19mm)
- MT32036
- 19mm 90 ° BSPP Elbow
- MT32037
- Pipe; M200B 19mm
- MT32038-3
- 19mm Socket
- MT32039
- 25mm Male/Female Union Taper Seat
- MT32024
- 25mm Choke Pipe; M200B
- MT32025-3
- 25mm Equal T
- MT32027
- 25mm Exhaust Plug
- MT29681
- Hex Reducer 32 x 25mm
- MT32028
- RCV c/w Silencer and Union Elbow
- MT32044
- Petcock Valve Assembly - (Red Handle)
- MT29656
- 32mm Male/Female Equal Union Taper Seat
- MT32032
- 32mm Equal Pitcher T
- MT32029
- 38mm Choke Valve Handle
- MT30094
- 32mm Ball Valve
- MT32032
- 32mm 60° Cone Male/Male Adaptor
- MT32033
- Silencer c/w Union Elbow
- MT32043
- Elcometer Inspection Hatch Door
- MT28616
- ElcoFit™ Door Sealing Gasket
- MT28613
- Elcometer Inspection Door Fixings
- MT32049
- Elcometer Inspection Door Yoke
- MT32048
- 2355mm Single Spare Wheel Kit
- MT32047-3
- Contractor Decal Kit
- MT29603-4
- Contractor 24″ 300L 1 1 / 4 " Pusher Hose Assembly
- MT32046-3
Frequently asked questions
What's the hopper capacity?
The hopper holds 200 litres and loads to 468 kg with garnet grit or 880 kg with steel shot. The large capacity reduces refilling downtime on site.
What's the maximum working pressure?
The Elcometer 200C operates at a maximum working pressure of 12 bar. It must be used with an appropriate safety pressure relief valve.
Is this machine truly portable?
Yes. It is designed for mobile blasters and uses industry-standard remote control valves, grit valves, and 32 mm pipework for easy setup and maintenance. It weighs 205 kg.
What's the operating temperature range?
The machine operates between 0 and 60°C.
What spare parts are available?
Spare parts include valves, pipes, hoses, gaskets, seals, wheels, and door components. Each is identified by an Elcometer part number.
