Product Description

PLEASE NOTE: THIS PRODUCT HAS BEEN DISCONTINUED – Please contact us if you would like a recommendation of a unit to replace this model.

elcometer-204-ultrasonic-thickness-gauge-200

Pre-calibrated for ease of use, the Elcometer 204 Steel Ultrasonic Thickness Gauge provides a fast, accurate measurement of the thickness of steel.

Each gauge is supplied with an integrated steel “zero” plate to ensure the greatest accuracy. Supplied with a transducer & ultrasonic couplant, simply switch on the gauge and take readings. The inbuilt back light allows measurements in low light conditions.

  • Supplied with everything required to use straight from the box.
  • Low cost and easy to use.
  • Measure material thickness when there is access to only one side.

Specifications

Elcometer 204 Ultrasonic Thickness Gauge – Specifications

Part Number Description
C204—1 Elcometer 204 Steel Ultrasonic Thickness Gauge
Range 0.63mm to 199.99mm
Resolution 0.01mm
Accuracy ±2% of reading or ±0.5mm, depending on material and conditions
Weight 295g Including batteries
Dimensions 63 x 120 x 31mm
Operating Temperature -30°C to 50°C  depending on climatic conditions
Case Extruded aluminium body, nickle plated aluminium end caps
Battery Life 200 hours continuous use (alkaline dry batteries)
Battery Type 2 x LR6 (AA), alkaline dry batteries
Certificate Available Certificate of Calibration: issued for Fixed Calibration equipment and shows readings and traceability.
Accredited Certificate: can be issued for Fixed Calibration Equipment and a full UKAS traceable certificate is issued from an independent Calibration Laboratory.


Elcometer 204 Steel Ultrasonic Thickness Gauge
Packing list:

  • Elcometer 204 Steel Ultrasonic Gauge
  • Transducer with calibration certificate
  • Ultrasonic couplant
  • 2 x batteries
  • Carry case
  • Operating instructions

Data Sheet

Elcometer 204 Ultrasonic Thickness Gauge – Data Sheet

Elcometer 204 Ultrasonic Thickness Gauge Data Sheet

Accessories

Elcometer 204 Ultrasonic Thickness Gauge – Accessories

Part Number Description
T92015646 Transducer: Potted Right Angle 5.0MHz, 6.4mm (¼”) Transducer
T92015701 Ultrasonic Couplant – 120ml Bottle
T92015874 High Temperature Ultrasonic Couplant – 60ml Bottle
T92015617 Instrument Carry Case
T9205243- Test Wedge: 2 – 25mm in 6 Steps
T9205270- Test Wedge: 30 – 100mm in 8 Steps



Instruction Manual

Elcometer 204 Ultrasonic Thickness Gauge – Instruction Manual

Elcometer 204 Ultrasonic Thickness Gauge Instruction Manual
