The Leica Disto X4 Laser Distance Meter is a laser distance meter built for bright, outdoor environments, where a red laser point is hard to see and conventional meters struggle to aim. The Leica Disto X4 Laser Distance Meter solves that by adding a pointfinder camera with 4x zoom: line up the measurement point in the on-display crosshairs on the full colour, high-resolution screen and take a precise reading even in strong sunlight.
The Leica Disto X4 Laser Distance Meter improves on the X3 with the pointfinder camera and an auto-rotating display, and includes an on-board tilt sensor for Smart Horizontal mode and automatic levelling. The Leica Disto X4 Laser Distance Meter measures up to 150m with a typical accuracy of plus or minus 1mm and a laser dot of 6, 30 or 60mm with distance. Rugged construction makes it IP65 rated for water jet protection and dust-tight, and 2-metre drop tested, so it withstands tough jobsite conditions. Functions include minimum and maximum, area and volume, the painter function, Pythagoras, Smart Horizontal Mode, stake-out, and subtraction and addition, with memory for 30 displays.
Bluetooth transfers measurements to a computer or mobile device for use with the DISTO Plan App, where Sketch, Document and Smart Room features create CAD-ready floor and wall plans exported as .DXF or .DWG files. With the DST 360 smart tripod and adapter set, the Leica Disto X4 Laser Distance Meter becomes a measurement station that combines rotation, angle and distance for accurate Point-to-Point measurements. The Leica Disto X4 Laser Distance Meter runs on 2 x 1.5V AA batteries for up to 5000 measurements, measures 143 x 58 x 29mm and weighs 198g with batteries. The Leica Disto X4 is supplied by BAMR, South Africa's authorised distributor.
Leica Disto X4 Laser Distance Meter
The Leica DISTO X4 Laser Distance Meter is a DISTO designed for bright, outdoor environments. Measuring outside often? The DISTO X4 improves on the X3 by adding a pointfinder camera, which lets you aim your DISTO's laser point using the full colour, high-resolution display, simply line up your desired measurement point in the on-display crosshairs and you'll get a precise measurement.
- Pointfinder camera Line up your desired measurement point in the on-display crosshairs with 4x zoom for precise aiming
- Auto-rotating display
- On-board tilt sensor Smart Horizontal mode for automatic levelling
- Bluetooth connectivity Transfer measurements to your computer or mobile device and use seamlessly with DISTO Plan App
- Rugged construction IP65 rated and 2-metre drop tested
- Extended range measurement Measure up to 150m with the pointfinder camera and certified accuracy in any lighting
- DST 360 compatibility Works with smart tripod and adapter set to turn the X4 into a professional measurement station for Point-to-Point (P2P) measurements
- DISTO Plan App integration Access Sketch, Document, and Smart Room features to create detailed CAD-ready floor and wall plans, export as .DXF or .DWG files
Technical specifications
- Typical measuring accuracy
- ±1mm
- Range
- up to 150m
- Measuring units
- m, ft, in
- X-Range Power Technology
- Yes
- Distance in m
- 10, 50, 100m
- Ø of the laser dot in mm
- 6, 30, 60mm
- Pointfinder with 4x zoom
- Yes
- Memory
- 30 displays
- Measurements per set of batteries
- up to 5000
- Multifunctional end-piece
- automatic recognition
- Batteries
- type AA 2 × 1.5V
- Tripod thread
- Yes
- Protection class
- IP 65 - water jet protection and dust-tight
- Dimensions
- 143 × 58 × 29mm
- Weight with batteries
- 198g
Functions
- Minimum / maximum measurements
- Yes
- Area / volume measurement
- Yes
- Painter function
- Yes
- Pythagoras function
- Yes
- Smart Horizontal Mode™
- Yes
- Stake-out function
- a/b
- Subtraction / addition
- Yes
Specifications
Technical specifications
- Typical measuring accuracy
- ±1mm
- Range
- up to 150m
- Measuring units
- m, ft, in
- X-Range Power Technology
- Yes
- Distance in m
- 10, 50, 100m
- Ø of the laser dot in mm
- 6, 30, 60mm
- Pointfinder with 4x zoom
- Yes
- Memory
- 30 displays
- Measurements per set of batteries
- up to 5000
- Multifunctional end-piece
- automatic recognition
- Batteries
- type AA 2 × 1.5V
- Tripod thread
- Yes
- Protection class
- IP 65 - water jet protection and dust-tight
- Dimensions
- 143 × 58 × 29mm
- Weight with batteries
- 198g
Functions
- Minimum / maximum measurements
- Yes
- Area / volume measurement
- Yes
- Painter function
- Yes
- Pythagoras function
- Yes
- Smart Horizontal Mode™
- Yes
- Stake-out function
- a/b
- Subtraction / addition
- Yes
Packing List
Packing List
Comparison Table
Comparison Table
x = available on that modelx*, x** and x*** denote availability with model- or app-specific conditions.
| Group | Feature | D1 | D110 | D2 | X3 | D5 | X6 |
|---|---|---|---|---|---|---|---|
| Digital Pointfinder for outdoor measuring | x | x | |||||
| Max. range | 40m | 60m | 100m | 150m | 200m | 250m | |
| General | Accuracy | ± 2mm | ± 1.5mm | ± 1.5mm | ± 1mm | ± 1mm | ± 1mm |
| General | P2P function | x* | x* | ||||
| General | Extra durable housing with IP65 and 2 m drop-tested | x | x | ||||
| General | Wireless interfaces (low energy) | Bluetooth® 4.2 | Bluetooth® 4.2 | Bluetooth® 4.2 | Bluetooth® 4.2 | Bluetooth® 5 | Bluetooth® 5 |
| Computer interface | Data transfer to DISTO Plan and DISTO compatible apps | x | x | x | x | x | x |
| Computer interface | Data transfer to any software or app | x | x | x | |||
| Computer interface | Download data via USB-C interface | x | |||||
| Computer interface | Distance measurement from device | x | x | x | x | x | x |
| Distances | Dimensional measurements on objects | x | x | x | x | x | x |
| Distances | Indirect distance measurement over obstacles | x | x | x | |||
| Distances | P2P function – any distance between 2 points | x* | x* | ||||
| Distances | Rectangular shapes (length and width) | x | x | x | x | x | |
| Areas | P2P – Smart Area function for complex shapes | x* | x* | ||||
| Areas | Measure in picture – facades, vertical boards | x | |||||
| Volume | Rectangular shapes (length, width, height) | x | x | x | x | ||
| Volume | Using Pythagoras Theorem | x | x | x | x | ||
| Widths | Measure in picture – width measurement | x | |||||
| Widths | P2P function | x* | x* | ||||
| Widths | Smart functions using distance and inclination for calculation | x | x | x | |||
| Heights | Height profile | x | x | ||||
| Heights | P2P function | x* | x* | ||||
| Heights | Inclinations | x | x | x | |||
| Slopes | Smart functions using distance and inclination for calculation | x | x | ||||
| Slopes | P2P function | x* | x* | ||||
| Slopes | Measuring in picture – diameter of objects | x | |||||
| Slopes | Continuous measurement – tracking | x | x | x | x | x | x |
| Diameter | Stake out | x | x | x | x | ||
| Positioning | P2P – DXF data capturing on device | x | |||||
| Positioning | Draw and measure (floor) plans | x** | x** | x** | x** | x** | x** |
| Positioning | P2P – point capturing for floor plans and facades | x*** | x*** | ||||
| Positioning | Smart Room – measure and draw | x** | x** | x** | |||
| Positioning | PDF, JPG and DXF exports | x** | x** | x** | x** | x** | x** |
| Planning and | Measure and document on pictures | x** | x** | x** | x** | x** | x** |
| documentation | P2L - documenting positions based on a reference line | x | |||||
| documentation | Creating measurement reports (JPG and CSV) | x | |||||
| documentation | Touchscreen | x | |||||
| documentation | Trigger measurement with gestures | x | x | ||||
| documentation | Favourite keys | x | x | x | |||
| documentation | Automatic end piece | x | x | x | x | ||
| Usability | Keyboard mode | x | x | x |
Frequently asked questions
How does the X4's pointfinder camera improve on the X3?
The X4 adds a pointfinder camera with 4x zoom and a full-colour, high-resolution display. You align your measurement point using on-display crosshairs rather than relying on the laser dot alone.
What's the measurement range and accuracy of the X4?
The X4 measures up to 150m with typical accuracy of plus or minus 1mm. It displays results in metres, feet, or inches.
Can the X4 handle wet or dusty job sites?
Yes. The X4 carries IP 65 protection, providing water jet protection and dust-tight operation. It delivers up to 5000 measurements per battery set.
Does the X4 support indirect or complex measurements?
Yes. The X4 includes Pythagoras calculations, area and volume measurement, stake-out, and Smart Horizontal Mode for measurements over obstacles or at angles.
Can I use the X4 on a tripod?
Yes. The X4 has a tripod thread and a multifunctional end-piece with automatic recognition. The device stores up to 30 measurement displays in memory.
