Elcometer NDT CG10 Corrosion Ultrasonic Thickness Gauge - Discontinued

PLEASE NOTE: THIS PRODUCT HAS BEEN DISCONTINUED – Please contact us if you would like a recommendation of a unit to replace this model.

elcometer-ndt-cg10-corrosion-ultrasonic-thickness-gauge

Product Description

The Elcometer NDT CG10 Corrosion Ultrasonic Thickness Gauge is a fixed velocity gauge making it an affordable handheld precision tool that requires no special training to operate.

The Elcometer NDT CG10 Corrosion Ultrasonic Thickness Gauge will hold a single, user programmable velocity. Pre-calibrated to steel, for immediate inspection, the Elcometer NDT CG10 Corrosion Ultrasonic Thickness Gauge is the ideal model where one material is being tested day after day.

Whilst the gauge is supplied ready to measure steel the velocity can be quickly changed using the simple software program which is supplied with each unit, allowing other materials to be measured.



Elcometer NDT CG10 Corrosion Ultrasonic Thickness Gauge Advantages
Ready to use, straight from the box
Ideal for basic thickness measurements
Durable gauge and probe construction
Large backlight LED display
Tough, impact, water, dust & petroleum product resistant
Up to 200 hours battery life

Specifications

Elcometer NDT CG10 Corrosion Ultrasonic Thickness Gauge – Specifications

Model & Part Number CG10
Ultrasonic Corrosion Thickness Gauge
Material thickness digits display
Measurement Mode PE
Measurement Rate Manual 4 readings per second
Measuring Range 0.63 – 500mm
Measurement Accuracy ±0.01mm
Measurement Resolution 0.01mm
Velocity Calibration Range 1250 – 10,000m/s
Additional Features 1 programmable velocity,
pre-calibrated for steel
Transducer Probe Type dual element
Transducer Frequency Range 1 – 10MHz
V-path / dual path error correction automatic
Probe zero manual (via integrated probe disk)
Display 12.7mm high digits
Units (selectable) mm or inches
LED Backlight on / off / auto
Repeatability / Stability Indicator
Battery Type 2 x AA alkaline
Battery Life (approximate) 200 hours
Low Battery Indicator
Battery Save Mode auto
Operating Temperature -30 to 50ºC
Size (w x h x d) 63.5 x 114.3 x 31.5mm
Weight (including batteries) 284g
Aluminium case design with
gasket sealed end caps,
waterproof membrane keypad
Transducer Connector Type LEMO
RS232 Interface for programming only



Elcometer NDT CG10 Corrosion Ultrasonic Thickness Gauge Packing List:

  • Elcometer NDT CG10Corrosion Ultrasonic Thickness Gauge
  • Couplant
  • Carry case
  • User manual
  • Test certificate
  • 2 x AA batteries
  • Software
  • Transfer Cable

Data Sheet

Elcometer NDT CG10 Corrosion Ultrasonic Thickness Gauge – Data Sheet

Elcometer NDT CG10 Corrosion Ultrasonic Thickness Gauge Data Sheet



Instruction Manual

Elcometer NDT CG10 Corrosion Ultrasonic Thickness Gauge – Instruction Manual

Elcometer NDT CG10 Corrosion Ultrasonic Thickness Gauge Instruction Manual
