Elcometer 4695 Scrub Test Panels

Product Description

Elcometer supplies a wide range of Leneta Test Charts, from plain white to those having different patterns of black and white. Made from naturally bright, non-fluorescent white paper, these charts contain no optical brighteners that can affect instrumental color measurements.

Leneta Test Charts are the market standard in today’s coatings industry. Foil Card substrates of steel, aluminum, glass and plastic are also available. Leneta Test Charts are available in boxes & cases.

Charts can be used with the Elcometer 4340 Motorised Film Applicator

Scrub Test Panels

In a typical scrub test, the coating is applied to the Leneta Scrub Test Panel at a specified film thickness, allowed to dry and then subjected to scrubbing with a straight-line scrub tester.

When used in accordance with ASTM D2486, Method A, a 10mil shim is inserted under the panel to accelerate failure and thereby reduce testing time. The scrub resistance is the number of scrub cycles required to remove the coating to a specified end point.

Alternatively, the loss in weight is determined after a specified number of scrub resistance cycles, with calculation of equivalent loss in film thickness.

These Scrub Test Panels are ideal for use with the Elcometer 1720 Washability & Abrasion Testers.

The Elcometer 4695 Leneta Test Charts can be used in accordance with:

• AS/NZS 1580.213.1
• ASTM D 344
• ASTM D2805
• ASTM D 2486
• ASTM D 5150
• ASTM D 6441
• BS 3900-D4*
• DIN 53162-2
• FTMS 141 4121
• ISO 2814

* Standards not in bold have been superseded but are still recognised in some industries

Specifications

Elcometer 4695 Leneta Scrub Test Panels – Specifications

Part Number   Description Chart Dimensions Box Weight Quantity per Box Boxes per Case
Box Case
K0004695M068 K0004695M268 Black Scrub Test Panel P121-10N 165 x 432 mm 0.91kg 100 5
K0004695M069 K0004695M269 White Scrub Test Panel P123-10N 165 x 432 mm 0.91kg 100 5

Packing List

  • Elcometer 4695 Leneta Test Charts

Data Sheet

Elcometer 4695 Leneta Scrub Test Panels – Data Sheet

Elcometer 4695 Leneta Scrub Test Panels Data Sheet

Standards

Elcometer 4695 Leneta Scrub Test Panels – Standards

The Elcometer 4695 Leneta Test Charts can be used in accordance with:

• AS/NZS 1580.213.1
• ASTM D 344
• ASTM D2805
• ASTM D 2486
• ASTM D 5150
• ASTM D 6441
• BS 3900-D4*
• DIN 53162-2
• FTMS 141 4121
• ISO 2814

* Standards not in bold have been superseded but are still recognised in some industries

Accessories

Elcometer 4695 Leneta Scrub Test Panels – Accessories

Part Number Description
KT001720P012 ASTM Test Foil 250µm
