Product Description

The Elcometer 3000 Motorised Clemen Hardness Tester is a robust and accurate instrument for evaluating the resistance to scratching of a coated surface. The sample can be metal, wood, glass, plastic or other hard materials. A tool is fitted with an hemispherical tip of 1mm diameter (standard), lowered gradually on to the sample surface which is then pulled linearly 60mm. As the sample is pulled the tool lowers automatically on to the sample, moves along the sample and gently rises up at the end of the stroke.To ensure consistent, repeatable and reproduceable tests, the Motorised Clemen Hardness Tester automatically brings the tool gently in contact with the sample, moves across the coating and then lifts it with the automatic Start/Stop function. Depending on the load applied, varying degrees of penetration of the tool into the coating are observed – from a superficial trace to total destruction.If the coating is completely removed during the test, the contact of the tool with the metallic substrate is indicated by a lamp and voltmeter indicator. Elcometer offer a range of cutting tools, please see Accessories tab.



Specifications

Elcometer 3000 Motorised Clemen Hardness Tester – Specifications

Part Number Description Certificate
K3000M003 Elcometer 3000 Motorised Clemen Hardness Tester ο
Load Range 0 – 5kg (0 – 11lb)
Sample Size 75 x 150mm (3 x 6″)
Sample Thickness Standard: 0.5 – 3mm (0.02 – 0.12″)
Extended*: 5 – 20mm (0.2 – 0.8″)
Operating Temperature 5 to 40°C (41 to 104°F)
Humidity Range Not to exceed 80% relative humidity up to 31°C (88°F), decreasing linearly to 50% at 40°C (104°F).
Dimensions 460 x 280 x 330mm (18 x 11 x 13″)
Weight 20kg (44lb)
Packing List Elcometer 3000 Motorised Clemen Hardness Tester, 1kg weight (x4), tungsten carbide ball tool; 1mm (0.04″) mains leads (UK, EUR and US) and operating instructions.



ο Optional Calibration Certificate available
* Using the optional Adjustment Kit

Data Sheet

Elcometer 3000 Motorised Clemen Hardness Tester

– Data Sheet

Elcometer 3000 Motorised Clemen Hardness Tester – Data Sheet

Standards

Elcometer 3000 Motorised Clemen Hardness Tester – Standards

The Elcometer 3000 can be used in accordance with:

  • AS/NZS 1580.403.1
  • BS 3900-E2
  • DIN 53799
  • ECCA T12
  • EN 13523-12
  • ISO 1518-1:2011
  • JIS K 5600-5-5

Standards not in bold have been superseded but are still recognised in some industries.

Accessories

Elcometer 3000 Motorised Clemen Hardness Tester

– Accessories

KT003000P021 Tungsten Carbide Ball Tool; 1mm (0.04″)
KT003000N001 Tungsten Carbide Cutting Tool; 2mm (0.08″)
KT003000N015 Adjustment Kit to test from 5 to 20mm (0.02 to 0.8″)
KT007210M001 Illuminated Microscope (x30)
KT001546N002 Cross Cut Magnifying Glass
