The Digital Inclinometer 360 degree Angle Gauge Module is an electronic digital level for measuring angles and slopes. It can be used on its own or fixed to machinery and straight edges, displaying level, plumb and every angle in between. It solves the layout and alignment problems common with ordinary builders levels, where reading a bubble vial by eye introduces error when setting grades for stairways, windows, doors and roof members.
The Digital Inclinometer 360 degree Angle Gauge Module reads angles in degrees or slopes as a percentage, where rise over run is expressed as cm per 1m. It measures across a full 360 degrees, shown as four 90 degree quadrants, and 0 to 100% over eight segments at every 45 degrees, with accuracy of 0.1 degrees across all angles. An oversize LCD shows clear, easy to read figures and automatically inverts for overhead measurements, while an acoustic signal sounds at level and plumb. A data hold function freezes the reading until over-ridden, and the user can re-calibrate at any time. Auto shut off occurs after 5 minutes, and the module runs on a 9V PP3 alkaline cell.
The Digital Inclinometer 360 degree Angle Gauge Module measures 168 x 54 x 36mm and is offered in several configurations: P175 module only, P250M module with a 250mm level and magnet, P600 with a 600mm level and P1000 with a 1000mm level. An integrated laser version is also available.
Used across construction and industry, and supplied by BAMR, South Africa's authorised distributor.
Digital Inclinometer 360 degree Angle Gauge Module
The Digital Inclinometer 360 degree Angle Gauge Module is a very robust, simple electronic digital LCD display inclinometer, which can be used independently or affixed to machinery or straight edges. It measures angles in degrees or slopes in percentages. It is the most complete program of digital electronic levels without compromises. Available in lengths from 25cm to 180cm.
- Measures Angles in degrees
- Measures angles in percentages
- Rise over run % = cm/1m
- Acoustic signal at level and plumb
- Accuracy to 0.1 for all Angles
- Re-calibration by User possible at any time
- Display automatically inverts (turns over) for taking overhead measurements
- LCD display operates through 0 to 360°
- Data hold freezes reading until over-ridden
- Display 0-90° (in 4 quadrants), 0-100% (in 8 segments, ie. every 45°)
Also available to buy online at GaugeIt, our online store.
When to use the Digital Inclinometer 360 degree Angle Gauge Module
Reach for this when you need to set or check an angle or slope, used on its own or fixed to machinery or a straight edge. It reads angles in degrees and slopes in percentages through a full 0 to 360 degrees, and comes in module-plus-level lengths from 250mm to 1000mm.
- 1Reads full 360 degreesThe LCD operates through 0 to 360 degrees across four quadrants, so it handles any orientation rather than only near-level work, and the display auto-inverts to stay readable for overhead measurements.
- 2Degrees or percentage slopeIt measures angles in degrees and slopes in percentage, with rise over run as cm per metre, so the same tool sets a precise angle or checks a fall or gradient.
- 3Acoustic signal at level and plumbAn audible tone at level and plumb lets the operator find the point without watching the display, which helps when the module is fixed in an awkward or out-of-sight position.
- 4User recalibration any timeThe user can recalibrate at any time, with accuracy to 0.1 degrees for all angles, so readings stay trustworthy in the field without sending the unit away.
Lower-budget alternatives
Ten minutes on a call with one of our specialists usually saves you from buying the wrong instrument.
Book a 10-minute callOr , our product assistant, for an instant answer.
When to use this
When to use the Digital Inclinometer 360 degree Angle Gauge Module
Reach for this when you need to set or check an angle or slope, used on its own or fixed to machinery or a straight edge. It reads angles in degrees and slopes in percentages through a full 0 to 360 degrees, and comes in module-plus-level lengths from 250mm to 1000mm.
- 1Reads full 360 degreesThe LCD operates through 0 to 360 degrees across four quadrants, so it handles any orientation rather than only near-level work, and the display auto-inverts to stay readable for overhead measurements.
- 2Degrees or percentage slopeIt measures angles in degrees and slopes in percentage, with rise over run as cm per metre, so the same tool sets a precise angle or checks a fall or gradient.
- 3Acoustic signal at level and plumbAn audible tone at level and plumb lets the operator find the point without watching the display, which helps when the module is fixed in an awkward or out-of-sight position.
- 4User recalibration any timeThe user can recalibrate at any time, with accuracy to 0.1 degrees for all angles, so readings stay trustworthy in the field without sending the unit away.
Lower-budget alternatives
Ten minutes on a call with one of our specialists usually saves you from buying the wrong instrument.
Book a 10-minute callOr , our product assistant, for an instant answer.
Specifications
Specifications
- Range
- 4x 90° (360°) ; 4×100%
- Accuracy
- 0,1° (%)
- Auto shut off
- 5 min.
- Hold Display
- Yes
- Calibrate Button
- Yes
- Acoustic signal
- vertical / horizontal
- Dimensions of Module
- 168 x 54 x 36
- Power supply
- 9V PP3 alkaline cell
- P175
- Module Only
- P250M
- Module with 250 mm level with Magnet
- P600
- Module with 600 mm level
- P1000
- Module with 1000 mm level
Frequently asked questions
What is the measuring range and accuracy of the Digital Inclinometer 360?
The instrument measures over four 90-degree quadrants, giving a full 360-degree range, and also reads slope in four 100% quadrants. Accuracy is 0.1 degree or 0.1%.
Can the inclinometer be attached to machinery or used as a level?
Yes. The module can be used independently or affixed to machinery or straight edges. It is available with levels in 250 mm (with magnet), 600 mm, and 1,000 mm lengths, or as the module alone.
What convenience features does the Digital Inclinometer 360 include?
The instrument has a hold display function, a calibrate button, and an acoustic signal for vertical and horizontal detection. Auto shut-off activates after 5 minutes of inactivity. Power is supplied by a single 9 V PP3 alkaline cell.
