Product Description

PLEASE NOTE: THIS PRODUCT HAS BEEN DISCONTINUED – Please contact us if you would like a recommendation of a unit to replace this model.



elcometer-ndt-cg30-corrosion-ultrasonic-thickness-gauge



The Elcometer NDT CG30 Corrosion Ultrasonic Thickness Gauge is an easy to use, versatile gauge, quickly calibrated on site by the user to give reliable, accurate thickness measurements on a wide variety of material substrates.

Taking 16 readings per second the high speed scan mode allows the user to quickly scan an area of material for defects or to identify its thinnest point, ideal for pipelines or large test surfaces.

Elcometer NDT CG30 Corrosion Ultrasonic Thickness Gauge Advantages

  • Multi calibration options: 1 point, 2 point and speed of sound for optimal accuracy
  • High speed scan mode: 16 readings per second
  • Wide range of interchangeable transducers
  • Easy to use menu structure
  • Tough, impact, water, dust & petroleum product resistant
  • Up to 200 hours battery life

Specifications

Elcometer NDT CG30 Corrosion Ultrasonic Thickness Gauge – Specifications



Model & Part Number CG30
Material thickness digits display
Measurement Mode PE
Measurement Rate : Manual: 4 readings per second
Scan Mode: 16 readings per second
Measuring Range 0.63 – 500mm
Measurement Accuracy ±0.01mm
Measurement Resolution 0.01mm
Velocity Calibration Range 1250 – 10,000m/s
Additional Features:
    High Speed scan mode
Calibration Options single, two point & velocity
Transducer Probe Type dual element
Transducer Frequency Range 1 – 10MHz
V-path / dual path error correction automatic
Probe zero manual (via integrated probe disk)
Display 12.7mm (0.5 inch) high digits
Units (selectable) mm or inches
LED Backlight on / off / auto
Repeatability / Stability Indicator
Battery Type 2 x AA alkaline
Battery Life (approximate) 200 hours
Low Battery Indicator
Battery Save Mode auto
Operating Temperature -30 to 50ºC
Size (w x h x d) 63.5 x 114.3 x 31.5mm
Weight (including batteries) 284g
Aluminium case design
with gasket sealed end caps,
waterproof membrane keypad
Transducer Connector Type LEMO



Elcometer NDT CG30 Corrosion Ultrasonic Thickness Gauge Packing List:

  • Elcometer NDT CG30Corrosion Ultrasonic Thickness Gauge
  • Couplant
  • Carry case
  • User manual
  • Test certificate
  • 2 x AA batteries
