Elcometer-138-conductivity-meter

Incorporating a flat sensor, the Elcometer 138 Conductivity Meter can measure the conductivity of a solution from a single drop of a sample.

Users can either place a sample on the conductivity meter’s flat sensor or immerse the meter’s sensor directly into the solution under test. The Elcometer 138 Conductivity Meter can be used for a broad range of applications, including: soluble salt concentrations, the electric conductivity (EC) of solutions used in agricultural operations and measuring rainwater pollution levels.

The Elcometer 138 Conductivity Meter features:

  • Highly precise measurements can be obtained from a single drop
  • Automatic range switching gives a wide measurement range of 1μs/cm to 19.99mS/cm
  • Out of range and low battery alarms
  • Visual indication when ambient temperature is outside the operating range

Specifications

Elcometer 138 Conductivity Meter – Specifications

Technical Specification
Part Number Description
E138-CM  Elcometer 138 Conductivity Meter
Measurement Principle 2 Electrode Bipolar AC
Measurement Mode Conductivity, Temperature
Minimum Sample Volume 0.12ml
Measurement Range 0 – 19.99mS/cm
Resolution 0 – 1999μS/cm: 1μS/cm
2.00 – 19.99mS/cm: 0.01mS/cm
Accuracy ±2% full scale (for each range)
Operating Temperature 5°C to 40°C
Operating Humidity 85% or less relative humidity (no condensation)
Battery Type 2 x CR2032 lithium batteries
Battery Life Approx. 200 hours of continuous use without back light
Weight 50g – including sensor and batteries
Dimensions 164 x 29 x 20mm

Data Sheet

Elcometer 138 Conductivity Meter – Data Sheet

Elcometer 138 Conductivity Meter Data Sheet

Standards

Elcometer 138 Conductivity Meter – Standards

The Elcometer 138 Conductivity Meter can be used in accordance with:

  • ISO 8502-6 / ISO 8502-9
  • US Navy PPI 63101-000 (Rev 27)

It can also be used in accordance with ISO 8502-11; AS3894.6A and SSPC Guide 15
