TH200 Shore A Digital Portable Hardness Tester - Discontinued

PLEASE NOTE: THESE PRODUCTS HAVE BEEN DISCONTINUED – Please contact us if you would like a recommendation of a unit to replace any of these models.
TH200 Shore A Digital Portable Hardness Tester

Product Description

The TH200 Shore A Digital Portable Hardness Tester is used for shore hardness testing.

  • Pocket size model with integrated probe
  • Meets DIN 53505, ASTM D 2240, ISO 7619
  • RS-232C data output
  • Operating stand optional
  • Bright & clear LCD display
  • 300 hours continuous use with standard batteries:no cables!

Applications

  • Good measurement accuracy and repetitiveness.
  • Constant measurement force, to eliminate the errors caused by artificially applied different force.
  • The operation handle evenly applies the force to the sample and adjusts the testing height to meet the measurement of different sample thickness.

Functions

  • TH200 cancels and locks in the peak value, makes the average value calculation and under-voltage alarming.
  • The RS232 communication cable connector to be carried out with the machine can carry out the data communication with computer.
  • Automatically switch off.
  • Measuring range: 0-100HA
  • Measurement deviation: within 20-90HA
  • ±1 grade

Specifications

TH200 Shore A Digital Portable Hardness Tester – Specifications

Description Specification
Test scales available Shore A
Standards DIN53505, ASTM D2240
Result display Hardness result, Average value, Max value (peak value lock), Battery indication
Result display resolution 0.1 unit
Data output RS232
Statistics Total test, Highest hardness, Average
Features Automatic shut off, battery low alarming
Operating temperature 0 – 40 deg C
Power requirements 3 x 1.25V batteries (V357)
Battery life 300 Hours
Dimensions 145g



Data Sheet

TH200 Shore A Digital Portable Hardness Tester – Data Sheet

TH200 Shore A Digital Portable Hardness Tester Data Sheet

Accessories

TH200 Shore A Digital Portable Hardness Tester – Accessories

Optional Accessories

  • RS232 communication cable
  • Operating Stand TH210FJ
  • TH210 4.5V AC/DC power adapter

The Operating Stand improves measurement accuracy and repetitiveness. It is possible to obtain constant measurement force, to eliminate the errors caused by different forces applied artificially.

The operation handle evenly applies the force to the sample and adjusts the testing height to meet the measurement of different sample thickness.

Instruction Manual

TH200 Shore A Digital Portable Hardness Tester – Instruction Manual

TH200 Shore A Digital Portable Hardness Tester Instruction Manual
